Usage and Maintenance Notes Strictly match the model Different series of air compressors (such as GA, GHS, ZR, etc.) require the use of corresponding model-specific oils. Mixing or using the wrong type may cause equipment damage and affect warranty. Regular replacement and inspection Replace according to the specified cycle in the equipment manual (synthetic oil usually has a longer cycle than mineral oil), and replace oil filters, air filters, etc. at the same time. Regularly test the oil quality (such as viscosity, moisture content, impurity content) to avoid failures caused by deteriorated oil. Storage and refilling The oil needs to be stored in a sealed manner in a cool and dry place to avoid contamination; when refilling, ensure that the tools are clean to prevent impurities from entering the oil circuit system.

Atlas Copco 2906067400，The air compressor maintenance kit is a standardized spare parts combination designed for common maintenance scenarios. It integrates the key components required for maintenance into a single toolkit. This integrated design eliminates the hassle for maintenance personnel of searching and matching parts separately. Especially for complex equipment such as screw-type air compressors and oil-free air compressors, it significantly shortens the maintenance preparation time and improves maintenance efficiency. The spare parts in the maintenance kit are all genuine products from the original factory or those that meet the equipment specifications. They have undergone strict testing and certification and can perfectly match the original components of the air compressor.

Atlas Copco, as a globally renowned manufacturer of air compressors and industrial equipment, uses rolling bearings in its equipment as one of the core components ensuring the efficient and stable operation of the machinery. These bearings are usually specially designed or selected based on the structural characteristics and operating conditions of different models (such as screw-type, piston-type, and centrifugal air compressors), and they have high matching accuracy and reliability.

Working Principle Torque Transmission: The torque output by the motor is transmitted through the outer teeth of the coupling, and then via the inner teeth of the intermediate sleeve to the compressor shaft, achieving power transmission. Flexible Compensation: Axial Offset: The axial clearance between the inner and outer teeth allows for a small amount of axial displacement of the two shafts (typically ±0.5 to ±3mm). Radial Offset: The top of the outer teeth is made into a spherical shape (with the center of the sphere on the axis), allowing for a certain angular deviation between the two shafts (typically ≤1°). Angular Offset: Through the sliding and rolling of the tooth surfaces, the angular errors between the two shafts are compensated. Buffering and Vibration Reduction: The lubricating oil fills between the teeth and can absorb some vibration and impact loads, reducing equipment noise.

Atlas Copco 3001160210,The air contains solid impurities such as dust, sand particles, and fibers. If these impurities enter the interior of the air compressor along with the air, they will cause wear on the components of the air compressor. For example, in a piston-type air compressor, the impurities may intensify the friction between the piston ring and the cylinder wall, shortening the service life of the piston ring and the cylinder. In a screw-type air compressor, the impurities may enter the gap between the screw rotors, affecting the normal operation of the rotors and causing accelerated wear of the rotors, and even potentially resulting in severe faults such as rotor jamming.The air filter can effectively intercept solid particles in the air, ensuring that the content of solid particles in the compressed air output complies with relevant standards. In some application scenarios where the quality of compressed air is highly demanded, such as in the food, pharmaceutical, and precision instrument manufacturing industries, even tiny solid particles can affect product quality or equipment operation.

"D70" might refer to the diameter specification of the conveying disc (such as 70mm), which is used to accommodate materials of specific sizes (such as small fasteners, accessories, etc.); "10" might be related to the rated conveying capacity, the applicable pressure parameters (such as 10bar), or the installation interface specifications.
