China Atlas Copco Control Valve Kit Manufacturer, Supplier, Factory

Atlas Copco 2230004015，Load solenoid valve: Usually a two-position three-way normally closed valve. When powered on, it allows compressed air to enter the cylinder pipe of the intake valve from the oil-gas tank, opening the intake port; when powered off, it cuts off the air path and discharges the air in the cylinder, closing the intake port. For example, the load solenoid valve of Ingersoll Rand achieves this function through PLC instructions. Safety relief solenoid valve: Mostly a two-position two-way normally open valve. When the air compressor is unloaded or shut down, it is powered off, releasing the gas in the oil-gas tank to the intake filter to ensure the system pressure drops to a safe range. In small air compressors, the solenoid valve connects the cylinder outlet to the outside when the machine is shut down to release residual pressure and prevent the motor from starting under load, causing overload; when starting, it closes the pressure relief channel to allow compressed air to be normally filled into the air tank. For example, the safety relief solenoid valve of Fuxinair air compressors indirectly regulates the movement of mechanical devices by controlling the opening and closing of the oil circuit.

All these filter components must be equipped with original Atlas Copco parts to ensure filtration efficiency and equipment compatibility. During maintenance, it is necessary to check and replace them according to the specified cycle in the equipment manual to avoid equipment failure due to filter failure.

Atlas Copco WD80 Operating Instructions Regularly check the levels of engine oil, fuel, and coolant to prevent equipment damage due to insufficient oil or water. Clean or replace the air filter and oil filter to prevent dust from entering the engine or compression system. Before starting, confirm that the exhaust pressure setting is correct and matches the requirements of the downstream equipment. Before long-term storage, empty the fuel and coolant (especially in low-temperature environments) to prevent cracking or corrosion due to freezing.

Atlas Copco 2906082800,The air compressor maintenance kit is an essential component for ensuring the safe operation of the air compressor system. It is mainly used for preventive maintenance and upkeep, ensuring the long-term stable operation of the equipment. The core protection function is to monitor the temperature of the storage tank, cooling water outlet temperature, and other parts through over-temperature protection. When the temperature reaches ≥ 120℃, it triggers an audible and visual alarm and automatically shuts down the machine. Overpressure protection: It detects the pressure of the storage tank in real time. When the pressure exceeds the limit, it automatically shuts down to protect the equipment safety. Oil shortage protection: It monitors the pressure of the lubrication system. When the oil pressure is abnormal, it forcibly shuts down to prevent mechanical dry friction damage. Water shortage protection: Specifically for water-cooled air compressors, it triggers a shutdown when the cooling water flow is abnormal. The filtration system functions as follows: The air filter: Filters impurities in the air entering the air compressor, such as dust, particles, and oil stains, to ensure the quality of the compressed air. The oil separator: Separates the lubricating oil from the compressed air to ensure the recycling of the lubricating oil and reduce the oil content in the compressed air. The oil filter: Filters the impurity particles in the lubricating oil to maintain the cleanliness of the lubricating oil.

The oil filter (oil filter) of the Atlas Copco injection-type screw compressor is an indispensable core component in the lubrication system. Its main function is to filter impurities (such as metal debris, oil sludge, dust, etc.) from the lubricating oil, protecting the key moving parts like screw rotors, bearings, and gears, preventing increased wear, and maintaining the cleanliness and performance stability of the lubricating oil.

The Atlas Copco UD + series of filters come in multiple specific models (such as UD9+, UD15+, etc.), each corresponding to different processing flow rates and applicable equipment. If you need to know the parameters, compatible models or purchasing information for a specific model, it is recommended to obtain detailed information through the official channels of Atlas Copco or authorized dealers.
