China Atlas Copco Industrial Air Compressor PM Kit Manufacturer, Supplier, Factory

1900071151 The working principle of the regulator for Atlas Copco centrifugal air compressor ZH10000: The inlet regulating vane mechanism adjusts the air flow and pressure entering the compressor by changing the angle of the vane. It can maintain a constant pressure within the adjustable range. This mechanism is installed within an effective range of 1-1.5 times the pipe diameter from the impeller. It can save a significant amount of energy within the adjustable range of 65% - 100% of the air volume.

Atlas Copco Air Compressor "Water Level Sensor" Quick Diagnosis and Common Issues False Alarm / Failure to Report: Check if the installation is loose, if the probe is clogged / blocked or covered; Calibrate or replace the sensor. Continuous Alarm: Check if the drain valve is blocked or if the control logic is abnormal; Clean the valve group and piping. Abnormal after Replacement: Verify the part number, wiring and range / upper and lower limit settings; Reset / re-calibrate if necessary.

ATLAS COPCO's FILTER KIT DD/DDP 130 + Usage and Maintenance Tips: The filter element should be replaced regularly based on the operating time of the equipment or the monitoring results of the compressed air quality. It is generally recommended to follow the maintenance cycle recommended by ATLAS COPCO to avoid affecting the efficiency of the dryer or causing excessive pressure drop due to clogged filter elements. The replacement process requires closing the relevant air path and releasing the pressure. The operation should comply with safety regulations. It is recommended to be carried out by professionals in accordance with the equipment manual to ensure correct installation.

The Importance of the Air Intake Valve in Atlas Copco Air Compressors and Its Connection to Energy Saving The adjustment accuracy of the intake valve directly affects the energy consumption of the air compressor: If the intake valve is not closed tightly , the air compressor will still consume additional power during unloading (about 30% - 50% of full load), and long-term operation will significantly increase electricity costs. The slide valve type and other continuously variable intake valves can adjust the intake volume in real time according to the actual gas consumption, and are 10% - 20% more energy-efficient than traditional butterfly valve types . In summary, the intake valve is the "breathing valve" of the air compressor. Its performance and condition are crucial to the operating efficiency, energy consumption, and stability of the equipment. Regular maintenance and correct selection are the key to ensuring the economic operation of the air compressor.

Maintenance and replacement suggestions for the muffler of Atlas Copco air compressors (industrial compressors): Regularly inspect the appearance of the muffler for any damage, blockages, or looseness. If the sound-absorbing material is exposed or the interior is clogged (such as excessive oil contamination), it will reduce the muffling effect. It is necessary to clean or replace it in time. When you notice an abnormal increase in the noise from the compressor during operation, check if the muffler is ineffective. If necessary, replace the original factory parts to ensure the muffling effect and equipment compatibility. When replacing, select the corresponding muffler specification based on the compressor model (such as interface diameter, rated flow, temperature and pressure resistance parameters, etc.). It is recommended to use Atlas Copco original products to avoid affecting the muffling effect or causing excessive air flow resistance due to size or performance mismatch.

Maintenance and Fault Handling of the Oil Temperature Electronic Elektronikon Control Module of Atlas Copco Air Compressors If there are abnormal oil temperature readings, the heating/cooling system does not respond, or the oil temperature protection is triggered frequently, it may be related to this control module. Maintenance suggestions: First, check whether the oil temperature sensor and connection lines are normal. Eliminate front-end signal faults; If the module itself is faulty, it is recommended to replace the original factory parts to ensure control performance. After replacement, calibration of parameters through special tools is required to make it match the model; Regularly check the module status through the self-check function of the Elektronikon system to promptly detect potential problems.
