I. Working Principle The safety valve is designed based on the principle of force balance. It mainly consists of a valve seat, a valve core, a spring, and a regulating mechanism. When the system pressure exceeds the spring's preload force, the valve core is pushed up, and the medium (compressed air) is discharged; when the pressure drops to the return seat pressure, the spring pushes the valve core back to its original position, closing the valve. Key parameters: Opening pressure (set pressure): The pressure at which the valve begins to open, usually 1.05 to 1.1 times the working pressure. Emission pressure: The pressure when the valve reaches its maximum opening height, generally ≤ 1.1 times the opening pressure. Return seat pressure: The pressure when the valve is closed, usually 10% to 15% lower than the opening pressure. Sealing pressure: The maximum pressure at which the valve maintains sealing, generally 90% of the opening pressure.

The advantage that ATLAS COPCO takes in choosing the original X2 kit 8K lies in its matching filtration efficiency, dimensional accuracy with the Atlas Copco air compressor, which can maximize the filtration effect and reduce the risk of equipment failure caused by incompatible filter elements. During daily maintenance, timely replacement of the oil filter is one of the key steps to maintaining the efficient and stable operation of the air compressor.

Application scenarios and maintenance for Atlas Copco KIT THERM MPV C40 Applicable models for Atlas Copco KIT THERM MPV C40: Mostly used in medium-sized oil-lubricated screw compressors of Atlas Copco (such as some models of the GA series), especially suitable for working conditions with high requirements for pressure stability and oil-gas separation efficiency (such as precision manufacturing, food and pharmaceutical industries). Maintenance points: Atlas Copco KIT THERM MPV C40: Regularly check for any leakage in the valves (judged by the rate of pressure drop); Clean the valve cores and sealing surfaces to avoid jamming caused by oil stains and impurities; If the temperature sensing element fails, it needs to be replaced in time to maintain the constant temperature control function.

Maintenance and Care Regularly replace filters: air filter, oil filter, oil-gas separator. Prevent impurities from entering the system. Check the lubricating oil: oil level, oil quality (oxidation, emulsification). Replace the oil according to the manufacturer's recommended schedule. Clean the cooling system: For air-cooled models, clean the radiator regularly; for water-cooled models, check the water quality and temperature. Tighten bolts: Prevent vibration from causing bolts to loosen, which may lead to safety hazards. Monitor operating parameters: Regularly record exhaust temperature, pressure, current, etc. Address any abnormalities promptly.

Maintenance tips for Atlas Copco air compressor thermostat kit: Regularly remove the thermostat valve for cleaning, remove foreign substances that may exist in the lubricating oil, and prevent blockage. You can put the valve core in 80℃ water to observe. If the valve core expands fully in this environment and is 10-15mm longer than at normal temperature, then the valve core is normal. If there are aging or other issues, the thermostat valve needs to be replaced.

Purchase Recommendation for Pressure Sensors of Atlas Copco Compressors Pressure sensors have high requirements for measurement accuracy and stability. It is recommended to purchase original factory parts through our authorized channels. Inferior sensors may cause unstable equipment operation due to insufficient accuracy or poor reliability, and even pose safety hazards. Pressure sensors are the "nerve endings" of air compressor automation control. Their performance directly affects the operating efficiency and safety of the equipment, and should be given special attention during daily maintenance.
