Choosing the Atlas Copco WUX service package can help users reduce equipment downtime, increase production efficiency, and prevent equipment damage caused by improper maintenance. It is an important service solution for ensuring the continuous and reliable operation of Atlas Copco equipment.

I. Working Principle The safety valve is designed based on the principle of force balance. It mainly consists of a valve seat, a valve core, a spring, and a regulating mechanism. When the system pressure exceeds the spring's preload force, the valve core is pushed up, and the medium (compressed air) is discharged; when the pressure drops to the return seat pressure, the spring pushes the valve core back to its original position, closing the valve. Key parameters: Opening pressure (set pressure): The pressure at which the valve begins to open, usually 1.05 to 1.1 times the working pressure. Emission pressure: The pressure when the valve reaches its maximum opening height, generally ≤ 1.1 times the opening pressure. Return seat pressure: The pressure when the valve is closed, usually 10% to 15% lower than the opening pressure. Sealing pressure: The maximum pressure at which the valve maintains sealing, generally 90% of the opening pressure.

Order will be placed on standard delivery conditions. After the order is placed, an order acknowledgement and tracking information will be provided to you by email.

Maintenance Points Regularly replace the filter element: Based on the usage environment and operating time (generally recommended every 2,000-4,000 hours) , replace the filter element to avoid increased pressure loss and reduced filtering effect due to blockage. Pressure difference monitoring: Some models are equipped with a pressure difference indicator. When the filter element becomes clogged to a certain extent, it will give a prompt, and it is necessary to replace it in time to ensure the normal operation of the system. Sealing check: Regularly check the interface sealing condition of the filtering component to prevent unfiltered compressed air from leaking into the downstream system. If you need to purchase filter elements or want to know about specific compatible models, it is recommended to refer to the PD295 filtering component technical document provided by Atlas Copco officially, or provide the detailed model of the air compressor (such as GA37, GA55)

The oil filter models corresponding to different models of the XAS series air compressors vary. Common oil filter models include 1613610500, 97125402, 9709003400, 9710009801, 1613610500, etc. (The specific model needs to be determined according to the specific model of the air compressor.)

Selection and precautions for coupling accessories of Atlas Copco compressors Model matching: The original factory accessories should be selected based on the compressor model (such as GA, G series), power, speed, pipe diameter, and pressure level to ensure that the dimensions, strength, and compensation are compatible. Original factory advantages: The original factory couplings of Atlas Copco have been tested specifically and have a high matching degree with the equipment, which can avoid vibration, leakage or safety hazards caused by size mismatch. Installation guidance: When replacing, refer to the equipment manual. If necessary, operate by professional technicians. Pay special attention to the alignment calibration (for transmission couplings) and pre-tightening force control (for pipe couplings).
