ATLAS COPCO's FILTER KIT DD/DDP 130 + Usage and Maintenance Tips: The filter element should be replaced regularly based on the operating time of the equipment or the monitoring results of the compressed air quality. It is generally recommended to follow the maintenance cycle recommended by ATLAS COPCO to avoid affecting the efficiency of the dryer or causing excessive pressure drop due to clogged filter elements. The replacement process requires closing the relevant air path and releasing the pressure. The operation should comply with safety regulations. It is recommended to be carried out by professionals in accordance with the equipment manual to ensure correct installation.

Atlas Copco 2901062200,The main function is core maintenance and support, covering key components such as intake valves, temperature control valve cores, rotary valves, and pressure maintaining valves, which are used for quickly repairing air compressor faults and ensuring its continuous and stable operation. The maintenance convenience is provided by standardized components, simplifying the maintenance process and reducing downtime, especially suitable for handling sudden failures and regular maintenance.

Atlas Copco 2910303200,Controlling intake air flow and ensuring stable supply. The intake valve regulates the amount of air entering the compressor by adjusting the opening degree of the valve plate or the movement of the piston, ensuring a stable supply of gas in the cylinder. When the system pressure reaches the set value, the intake valve closes to reduce the intake volume; conversely, it opens to increase the intake volume, thereby matching the load demand and maintaining operational efficiency. Implementing loading and unloading functions, when the air compressor starts or stops, the intake valve is controlled quickly to open or close through an electromagnetic valve or a cylinder to protect the internal components of the main unit. Capacity adjustment and energy-saving operation. Through the capacity adjustment valve or proportional adjustment mechanism, the intake valve can dynamically adjust the opening degree according to the actual gas usage demand, avoiding excessive compression of air and reducing energy waste.

Maintenance and Replacement Suggestions for Air Filters of Atlas Copco Screw Air Compressors Replacement Cycle: Generally, it is recommended to replace the air filter according to the specified cycle in the equipment maintenance manual (such as after 2000-4000 hours of operation, which may vary depending on the model and usage environment). If the dust concentration in the usage environment is high (such as in mines or cement plants), the replacement cycle should be shortened. Inspection Method: Regularly (e.g., weekly) check the cleanliness of the air filter. You can determine if it is clogged by using a pressure differential indicator (available on some models) — when the indicator value exceeds the set threshold, it is necessary to replace it promptly. Replacement Precautions: During replacement, ensure proper installation and good sealing; avoid allowing impurities to fall into the intake pipe during disassembly and assembly. After replacement, check for any leakage.

Atlas Copco 2906035200,The intake valve is the "breathing hole" of the air compressor, responsible for controlling the amount of fresh air intake to ensure the normal operation of the compressor and the output of compressed gas meeting the requirements. The intake valve is controlled on and off by the solenoid valve to achieve automatic loading and unloading of the compressor 5. When the pressure does not reach the set value, the intake valve is fully opened for loading; when the pressure is too high, it automatically unloads to protect the equipment and reduce energy consumption. The intake valve regulates the intake volume to control the output pressure and flow of the compressor, meeting the needs of different working conditions. The intake valve is equipped with a check valve to prevent reverse flow of compressed air and avoid damage to the exhaust system. The bypass valve of the intake valve is open during no-load or shutdown to prevent the formation of a vacuum in the separation oil tank and ensure the normal atomization and circulation of lubricating oil.

Atlas Copco 2906008200,Reducing gas temperature in multi-stage compression process, after the gas passes through the previous stage of compression, its temperature will rise sharply. The intercooler is located between the compression stages and can cool the high-temperature gas, providing lower-temperature and denser gas for the next stage of compression. Enhancing system efficiency The cooling process makes the compression process closer to isothermal compression, thereby reducing power consumption and improving the operational efficiency and economy of the entire compressor system. Separating condensate When the gas temperature drops, the water vapor and oil-gas mixture contained therein will condense. Some lubricating oil and water will condense into droplets, which can then be separated out, making the output compressed air cleaner. By effectively controlling the gas temperature, risks such as lubricant failure, equipment component damage, and even explosion caused by excessively high temperatures can be prevented. At the same time, the pollution risks to downstream equipment and pipelines can also be reduced.
