China 1621938400 & 2901905600 Manufacturer, Supplier, Factory

Order will be placed on standard delivery conditions. After the order is placed, an order acknowledgement and tracking information will be provided to you by email.

3002619010 Atlas Copco Maintenance and Replacement Guidelines Synchronous Replacement: It is recommended to replace the air filter, oil filter, and lubricating oil at the same time to reduce the oil pressure difference and energy consumption. Installation and Sealing: Install according to the manual torque. Replace all O-rings to avoid bypass of unfiltered air or oil. Pressure Difference Monitoring: Pay attention to the oil pressure difference and fuel consumption. If it abnormally increases, stop the machine for inspection and replacement. Environment and Load: In high dust / high humidity or heavy load conditions, the replacement cycle can be shortened to 3500 - 4000 hours or less.

Application scenarios and maintenance for Atlas Copco KIT THERM MPV C40 Applicable models for Atlas Copco KIT THERM MPV C40: Mostly used in medium-sized oil-lubricated screw compressors of Atlas Copco (such as some models of the GA series), especially suitable for working conditions with high requirements for pressure stability and oil-gas separation efficiency (such as precision manufacturing, food and pharmaceutical industries). Maintenance points: Atlas Copco KIT THERM MPV C40: Regularly check for any leakage in the valves (judged by the rate of pressure drop); Clean the valve cores and sealing surfaces to avoid jamming caused by oil stains and impurities; If the temperature sensing element fails, it needs to be replaced in time to maintain the constant temperature control function.

Atlas Copco 2906000600,Reducing gas temperature in multi-stage compression process, after the gas passes through the previous stage of compression, its temperature will rise sharply. The intercooler is located between the compression stages and can cool the high-temperature gas, providing lower-temperature and denser gas for the next stage of compression. Enhancing system efficiency The cooling process makes the compression process closer to isothermal compression, thereby reducing power consumption and improving the operational efficiency and economy of the entire compressor system. Separating condensate When the gas temperature drops, the water vapor and oil-gas mixture contained therein will condense. Some lubricating oil and water will condense into droplets, which can then be separated out, making the output compressed air cleaner. By effectively controlling the gas temperature, risks such as lubricant failure, equipment component damage, and even explosion caused by excessively high temperatures can be prevented. At the same time, the pollution risks to downstream equipment and pipelines can also be reduced.

Atlas Copco 2910303200,Controlling intake air flow and ensuring stable supply. The intake valve regulates the amount of air entering the compressor by adjusting the opening degree of the valve plate or the movement of the piston, ensuring a stable supply of gas in the cylinder. When the system pressure reaches the set value, the intake valve closes to reduce the intake volume; conversely, it opens to increase the intake volume, thereby matching the load demand and maintaining operational efficiency. Implementing loading and unloading functions, when the air compressor starts or stops, the intake valve is controlled quickly to open or close through an electromagnetic valve or a cylinder to protect the internal components of the main unit. Capacity adjustment and energy-saving operation. Through the capacity adjustment valve or proportional adjustment mechanism, the intake valve can dynamically adjust the opening degree according to the actual gas usage demand, avoiding excessive compression of air and reducing energy waste.

2906065600 Maintenance and Replacement Instructions for the Transmission Shaft Seal Kit of Atlas Copco Screw-Type Air Compressor If oil stains are found near the transmission shaft or there is oil leakage, or if the consumption of compressor lubricating oil increases abnormally, this may be due to the aging or damage of the seal kit. Therefore, it is necessary to check and replace it in time. When replacing, it is recommended to use the original seal kit and follow the equipment manual for operation to ensure that the installation direction of the sealing piece is correct and it is tightly attached. If necessary, special tools can be used for installation to avoid deformation or damage to the sealing piece.
