China SCREW COMPRESSOR parts Manufacturer, Supplier, Factory

Atlas Copco Air compressor HOURMETER The speedometer is the "barometer" of the operating condition of the air compressor. By monitoring the changes in its values, potential problems of the equipment can be detected in a timely manner, ensuring the efficient and stable operation of the unit. During daily operations, it is recommended to comprehensively analyze the equipment status by combining the other parameters displayed by the control unit (such as pressure, temperature, and current).

The solenoid valve of the air compressor is a key component for controlling the flow direction, on-off and system protection of compressed air. It is mainly divided into two types: loading solenoid valves and venting solenoid valves.

Failure causes and maintenance suggestions for Atlas Copco Air compressor O-ring Common failure causes: Long-term high-temperature aging leads to reduced elasticity, wear or scratches (such as impurities entering the sealing surface), improper installation (such as twisting, being too tight), incorrect selection (material not suitable for the medium or temperature). Maintenance precautions: Regularly inspect the condition of the O-ring. Replace it promptly if it shows signs of hardening, cracking, deformation or leakage. When replacing, clean the sealing groove and mating surface, remove oil stains, burrs and impurities. Avoid using sharp tools to scratch the O-ring during installation. If necessary, apply special lubricating grease (compatible with the medium) to assist in installation. Select matching specifications and materials for the O-ring based on the air compressor model and location.It is recommended to use original factory parts to ensure the sealing effect.

The air compressor pressure valve (also known as pressure control valve or pressure regulating valve) is a key component in the air compressor system used for controlling and regulating pressure. Its main function is to maintain the stability of pressure within the system, protect the safe operation of the equipment, and enable the automatic loading/unloading function of the air compressor.

Characteristics and Requirements of Air Compressor Gaskets Sealing: They should have good elasticity and adhesion, being able to tightly fill the minute depressions on the joint surface under pressure, ensuring no leakage. Temperature Resistance: They need to be able to withstand temperature changes during the operation of the air compressor (especially the higher temperatures of the cylinder body, exhaust pipelines, etc.), avoiding aging, hardening or losing elasticity under high temperatures. Pressure Resistance: They can withstand the rated pressure of the compressed air (usually 0.7-1.6 MPa) and instantaneous impact pressure, preventing being punctured by the pressure. Media Resistance: When in contact with the lubricating oil in the air compressor, the cooling liquid, or the trace impurities in the compressed air, they should have anti-corrosion and anti-swelling properties. Abrasion Resistance and Anti-Aging: During long-term use, they need to resist the effects of friction and environmental factors (such as humidity, oxidation), maintaining stable performance

Atlas Copco WUX Regulator Valve Maintenance and Precautions Regular Inspection: Observe whether the valve operates smoothly and check for any sticking (possibly caused by oil contamination or impurities); Check the sealing performance. If there is air leakage (such as air flowing through when the valve is closed), replace the sealing element. Cleaning and Calibration: Regularly disassemble and clean the valve core, valve seat, and diaphragm, removing oil stains and carbon deposits; Calibrate the pressure setting value according to the equipment manual to ensure adjustment accuracy (avoid excessive pressure fluctuations). Replacement Suggestions: If the valve cannot be adjusted, has severe air leakage, or suffers mechanical damage, it should be replaced promptly (it is recommended to use original factory parts to ensure compatibility with the compressor control system).
