Usage and Maintenance Notes Strictly match the model Different series of air compressors (such as GA, GHS, ZR, etc.) require the use of corresponding model-specific oils. Mixing or using the wrong type may cause equipment damage and affect warranty. Regular replacement and inspection Replace according to the specified cycle in the equipment manual (synthetic oil usually has a longer cycle than mineral oil), and replace oil filters, air filters, etc. at the same time. Regularly test the oil quality (such as viscosity, moisture content, impurity content) to avoid failures caused by deteriorated oil. Storage and refilling The oil needs to be stored in a sealed manner in a cool and dry place to avoid contamination; when refilling, ensure that the tools are clean to prevent impurities from entering the oil circuit system.

Maintenance and Replacement Suggestions for Atlas Copco Oil Coolers Regular Cleaning: For air-cooled coolers, clean the dust and oil stains on the fins regularly. For water-cooled ones, check if the water channels are blocked or clogged to ensure the cooling effect. Leak Check: During daily inspections, observe if there are oil stains on the surface and interface of the cooler. If leakage is detected, replace the sealing parts or the entire kit promptly. Replacement Timing: When the cooler shows severe corrosion, large-scale damage to the fins, or internal blockage causing abnormal oil temperature rise , it is recommended to replace the entire kit. Preferentially use Atlas Copco original accessories to ensure compatibility with the unit and cooling performance. The reliable operation of this kit directly affects the energy consumption, stability, and service life of the oil-free air compressor, and is an important guarantee for maintaining the efficient operation of the unit.

The thermostat valve of the Atlas Copco 2205526520 oil injection type screw compressor is composed of a temperature sensing element, a valve, a valve core, spring components, sealing elements, and threaded connection ports. When the temperature of the compressor reaches the set value, the temperature sensing element triggers the valve core to open the cooling path of the cooler. Then, the lubricating oil is cooled and recirculated, which can prevent the oil from overheating and deteriorating in quality, as well as the formation of carbon deposits that cause the air compressor to have a higher temperature and affect its efficiency.

First separation: The oil-gas mixture containing various-sized oil droplets, which comes out from the exhaust port of the air compressor main unit, enters the oil-gas tank. Most of the oil in the oil-gas mixture falls to the bottom of the tank under the action of centrifugal force and gravity. Second separation: The compressed air containing oil mist passes through the micrometer and fiberglass filter material layers of the oil-gas separation filter element for secondary separation. The oil particles undergo mechanisms such as diffusion, direct interception, and inertial collision aggregation, causing the suspended oil particles in the compressed air to quickly coalesce into large oil droplets. Under the action of gravity, the oil gathers at the bottom of the oil separation element and returns to the main lubricating oil system through the bottom concave area of the secondary return oil pipe inlet, thereby enabling the air compressor to discharge more pure and oil-free compressed air.

The Atlas Copco WUX series air compressor regulating valves are crucial components used to control the pressure, flow rate or load of the compressed air system. Their main function is to automatically adjust the intake volume or operating status of the compressor based on the demand for gas or changes in system pressure, in order to achieve energy-saving operation and stable gas supply.

Model and Purchase Suggestions Full part number: The part number of Atlas Copco's air filters usually consists of multiple digits (such as 1621735200, etc., and C142 might be its specification abbreviation), and the specific number should be based on the equipment manual or the body identification. Purchase Channel: It is recommended to query through Atlas Copco authorized service providers or the official website, providing the complete model of the equipment (such as GA110VSD+) and the factory serial number to ensure the precise compatibility of the accessories. Maintenance Cycle: Follow the recommendations in the VSD + model manual. Generally, it is recommended to replace the filters after 1500-3000 hours (adjust according to the dust concentration in the environment), or replace them promptly when the pressure difference indicator alarms.
