China 1619606800 Manufacturer, Supplier, Factory

Basic working principle A three-phase induction motor generates a rotating magnetic field by connecting to three-phase alternating current and passing it through the stator windings. The rotor cuts the magnetic lines of force in the magnetic field, generating an induced current, which is then subjected to electromagnetic force and rotates in accordance with the magnetic field (the rotational speed is slightly lower than that of the rotating magnetic field, and there is a slip rate). The electrical energy is converted into mechanical energy to drive the compression mechanism of the air compressor (such as pistons, screws, etc.) to operate. Adaptation features

Strict model matching: Different series of Atlas Copco air compressors (such as fixed type, mobile type, screw type, etc.) may require different specifications of coolant. Please select the corresponding original factory coolant based on the specific model of the equipment (such as GA75, XAS186, etc.). For example, some models use long-lasting coolant, with a replacement cycle of up to 8,000 - 10,000 hours. It is not allowed to mix this coolant with other brands or types of coolant at will.

Purchase and Maintenance Suggestions: Purchase Channel: Preferentially purchase through the official website of Atlas Copco or from our authorized certified service providers to ensure the authenticity of the parts and warranty; Installation and Maintenance: During installation, pay attention to the matching of interface sizes. Regularly clean the valve body to prevent impurities from blocking; If there is abnormal drainage (such as inability to open or close tightly), it is recommended to replace the original factory parts in time to avoid affecting the system operation.

1621875099 Atlas Copco filter material: Usually, it uses ultra-fine glass fiber composite filter material from the US HV Company or pure wood pulp filter paper from the Korean Ahlstrom Company. These filter materials have excellent filtering performance and can effectively retain impurity particles of 10-15 microns. 1621875099 The filtration accuracy of Atlas Copco is generally 10-15 micrometers, with a filtration efficiency of approximately 99%. The working temperature range is usually between -10℃ and 100℃, and the working pressure can reach 1.6 MPa.

Function: Filtering impurities: During the operation of the air compressor, the lubricating oil will generate metal debris due to friction with metal components, and the oil itself will also produce gums and other impurities due to heating and oxidation with air. The oil filter can effectively remove these impurities, such as metal particles and deteriorated oil substances. The filtration accuracy is usually between 5-15 μm, maintaining the cleanliness of the oil passage, preventing impurities from entering critical components such as bearings, gears, and main body cavities, reducing wear and extending the service life of the equipment. Ensuring lubrication effect: Ensure that the oil entering the main unit is pure, maintain good lubrication performance, allow the friction surfaces to be fully lubricated, reduce friction loss, and avoid faults caused by poor lubrication due to impurities, such as bearing damage, rotor seizing, etc.

Maintenance and replacement instructions for the transmission shaft seal kit of Atlas Copco screw air compressors If oil stains or oil leakage are observed near the transmission shaft, or if the consumption of compressor lubricating oil increases abnormally, it may be due to the aging or damage of the seal kit. Therefore, it is necessary to check and replace it in time. When replacing, it is recommended to use the original kit and operate in accordance with the equipment manual to ensure that the seal is installed in the correct direction and tightly attached. In case of necessity, special tools can be used for installation to avoid deformation or damage to the seal.
