ATLAS COPCO 1621049600 Maintenance and Replacement: During regular maintenance of the air compressor, it is necessary to check the condition of the gaskets. If any deformation, aging, or damage is found, they should be replaced immediately; After disassembly, if the gasket has undergone plastic deformation (such as a metal gasket), even if it is not damaged, it is recommended to replace it to avoid repeated use leading to sealing failure; When replacing, it is necessary to use gaskets of the same specification and material as the original ones. It is prohibited to substitute with different types of gaskets (such as using a rubber gasket instead of a metal gasket). Although the air compressor gaskets are small components, they are crucial for the sealing performance of the system. Choosing the appropriate gaskets and correctly installing and maintaining them can effectively reduce leakage faults, reduce energy consumption, and extend the service life of the air compressor.

6229031700 The non-return valve C77 of the oil-injected screw compressor from Atlas Copco reduces the impact of the backflow airflow on the internal components of the compressor, such as rotors and bearings, thereby extending the service life of the equipment.

Maintenance and Repair Recommendations for Metal Piston Valve Replacement Strategy: Triggered by running hours / pressure difference / abnormal temperature or abnormal listening, replace according to the manual; for the same level of gas valves, it is recommended to replace them as a set to avoid performance imbalance. Installation and Sealing: Thoroughly clean the valve groove and passage, replace all seals, and evenly tighten; conduct airtightness test after installation, and strictly prohibit bypassing unfiltered air. Condition Monitoring: Regularly record the valve cover temperature, pressure, and vibration; abnormal temperature rise / abnormal noise indicates valve plate / spring fatigue or seal failure, and should immediately stop the machine for inspection. Commissioning and Running-in: New machines or after major repairs, running-in and re-inspection are required to confirm no leakage and abnormal vibration.

The original Atlas Copco oil separator, with its precise filter design and strict quality control, can ensure long-term efficient operation. It is a key component for guaranteeing the gas quality of the air compressor and the economic performance of the system. When replacing it, it is recommended to choose original factory parts to match the equipment design standards, so as to avoid affecting the separation effect or causing system failures due to incompatibility issues.

Installation Specifications: When replacing the cooler kit, strictly follow the steps in the equipment manual to ensure that the sealing components are installed properly, and avoid leakage or insufficient heat dissipation due to improper assembly. Cleaning Preparations: Before installing the new cooler, it is recommended to clean the pipes and interfaces of the cooling system to remove internal residues such as impurities, scale, or oil sludge. Performance Testing: After replacement, start the compressor and monitor parameters such as operating temperature and pressure to confirm that the cooling system is working properly . Source of Spare Parts: It is recommended to purchase this service kit from Atlas Copco's official after-sales service or authorized dealers to ensure the original factory quality and compatibility of the spare parts. Non-original factory spare parts may have size deviations or material non-compliance issues, affecting cooling efficiency and equipment lifespan.

Failure causes and maintenance suggestions for Atlas Copco Air compressor O-ring Common failure causes: Long-term high-temperature aging leads to reduced elasticity, wear or scratches (such as impurities entering the sealing surface), improper installation (such as twisting, being too tight), incorrect selection (material not suitable for the medium or temperature). Maintenance precautions: Regularly inspect the condition of the O-ring. Replace it promptly if it shows signs of hardening, cracking, deformation or leakage. When replacing, clean the sealing groove and mating surface, remove oil stains, burrs and impurities. Avoid using sharp tools to scratch the O-ring during installation. If necessary, apply special lubricating grease (compatible with the medium) to assist in installation. Select matching specifications and materials for the O-ring based on the air compressor model and location.It is recommended to use original factory parts to ensure the sealing effect.
