Performance Characteristics
High corrosion resistance: The housing, output shaft, and gear set are all made of stainless steel, suitable for humid and corrosive environments.
Lubrication-free design: Equipped with low-friction blades and sealed bearings, no external lubrication is required, avoiding contamination risks.
High power-to-weight ratio: Compared with asynchronous motors of the same power, it is 75% lighter in weight and 85% smaller in size, facilitating installation and integration.
Widely adjustable speed range: Supports extensive adjustment from low speed to high speed, meeting the needs of different working conditions. The maximum rotational speed can reach 9400 rpm, and the maximum torque is 14.2 Nm.
Explosion-proof performance: Has ATEX explosion-proof certification. The pneumatic motor does not generate sparks during operation, suitable for explosive environments.
High sealing performance: Dual-axis sealing design, preventing water and contaminants from entering, prolonging service life. Technical Specifications
Power range: 0.24 - 0.39 kW (0.34 - 0.52 hp).
Rotation direction: Reversible, meaning it can rotate either clockwise or counterclockwise.
Certification: CE certification, with optional ATEX explosion-proof certification.
