The function of Atlas Copco Air Compressors ANGLE SEAT VALVE: By rotating the valve core, it controls the flow and cutoff of compressed air. At the same time, its own angle design (commonly 90° angle) is utilized to change the direction of the airflow. It is suitable for positions with limited space or where a turn is required in the air compressor pipeline system, simplifying the pipeline connection.
Application scenarios: Widely used in the intake, exhaust, cooling systems of air compressors, and various compression pipeline systems, especially in the auxiliary pipelines of small to medium-sized air compressors (such as GA series, G series, etc.).
Material and pressure resistance: The valve body is usually made of cast iron, cast steel or brass, and the sealing parts are mostly oil-resistant rubber or polytetrafluoroethylene to adapt to the working environment of compressed air (usually the working pressure is 7-13 bar, specific values need to match the air compressor model), with good pressure resistance and sealing performance.
Specification and model: The specification of the angle valve needs to match the pipe diameter (such as DN15, DN20, etc.). Different models of air compressors correspond to different parameters of the angle valve. Specific models can be referred to in the equipment technical manual (such as the part number is usually represented by a combination of numbers, such as 1622 series, 0300 series, etc.).
