The original Atlas Copco metal screw-type air compressor OSE kit application scenarios It is mainly used for the regular preventive maintenance of air compressors (such as maintenance based on operating hours or time periods), or as a replacement part for repairs when the equipment has specific faults. It is recommended to select the corresponding OSE kit according to the model of the air compressor (such as GA, G series, etc.) and the maintenance plan in the user manual.

Atlas Copco Air Compressor Oil Check Valve Maintenance and Replacement Check Period: It is recommended to conduct checks every 1-2 years or in accordance with the equipment manual (for example, after 4000-8000 hours of operation), and perform the checks simultaneously when replacing the filter and oil. Maintenance Points: Clean the valve core and valve seat to remove impurities; Check the wear of the seals and replace them promptly if they are aged; Test the elasticity of the springs. If the elasticity is insufficient, replace the entire valve. Replacement Precautions: Select original factory parts that match the model (such as Atlas Copco, Ingersoll Rand, etc. have dedicated oil check valves). Ensure that the size and pressure parameters are consistent; Pay attention to the direction during installation, and avoid installing it in the wrong direction; After replacement, start the equipment and check if the oil circuit pressure is normal and if there is any leakage.

Atlas Copco Installation and Maintenance Guidelines During installation, it is necessary to clean the oil stains and impurities from the surface of the distance ring, ensuring a tight fit with the mating parts without any gaps or skew. Avoid striking the edge of the distance ring (especially thin-walled parts), as this may cause deformation and affect the dimensional accuracy. During maintenance and inspection, check if the distance ring is worn, deformed or cracked. If any abnormalities are found, it should be replaced promptly; otherwise, it may lead to a decrease in the assembly quality and operational stability of the air compressor, causing vibration, abnormal noise or leakage, etc. Although the distance ring is a small standard part, its accuracy directly affects the assembly quality and operational stability of the air compressor. When selecting and installing, it is necessary to strictly follow the requirements of the equipment manual.

The specific components of the comprehensive maintenance kits for different models of Atlas Copco air compressors may vary. For instance, the 4000-hour service kit for the GX7 and GX11 models (part number 3002616290) includes air filter elements, oil filter elements, and oil-gas separator filter elements. However, for the ZR160-315 VSD model of air compressor, the component number of the 8000-hour maintenance kit is 3002616290. If you need to accurately understand the contents of the comprehensive maintenance kit for a particular model of air compressor, it is recommended to provide the specific model and serial number of the air compressor so that we can query the precise kit configuration.

Common Problems and Solutions for Atlas Copco Air Compressor Air Filter Enclosures Increased intake resistance: This may be due to foreign objects blocking the interior or an unreasonable design of the airflow channel. Clean the debris or replace the compatible enclosure. Sealing failure: This is often caused by aging seals or deformed enclosures. Replace the sealing ring or repair the enclosure (metal enclosures can be corrected, while plastic enclosures are recommended to be replaced directly). Enclosure damage: Minor damage to the metal enclosure can be repaired by welding. Severe deformation or cracking of the plastic enclosure requires a complete replacement to avoid affecting the filtration effect. Selecting an appropriate air filter enclosure and using high-quality filter elements can effectively ensure the long-term stable operation of the air intake system of the air compressor, reducing the wear of the main unit and energy loss.

Application scenarios and maintenance for Atlas Copco KIT THERM MPV C40 Applicable models for Atlas Copco KIT THERM MPV C40: Mostly used in medium-sized oil-lubricated screw compressors of Atlas Copco (such as some models of the GA series), especially suitable for working conditions with high requirements for pressure stability and oil-gas separation efficiency (such as precision manufacturing, food and pharmaceutical industries). Maintenance points: Atlas Copco KIT THERM MPV C40: Regularly check for any leakage in the valves (judged by the rate of pressure drop); Clean the valve cores and sealing surfaces to avoid jamming caused by oil stains and impurities; If the temperature sensing element fails, it needs to be replaced in time to maintain the constant temperature control function.
