Core Function Area
Status Overview Area
Operation Status Card: Displays the current operating status of the equipment (normal operation / stopped), operation mode (automatic / manual), and cumulative running time
System Pressure Card: Displays the current pressure value (7.2 bar) in real time, and shows the pressure range position through a progress bar
Equipment Temperature Card: Monitors the equipment temperature (58°C) in real time, and clearly marks the warning temperature threshold
Operation Control Area
Operation Control: Provides start/stop buttons to achieve basic operations of the equipment
Operation Mode Switching: Supports automatic/manual mode switching to adapt to different usage scenarios
Pressure Settings: Adjusts the target pressure value through a slider (currently set to 8.0 bar)
Emergency Shutdown Button: A prominent red button for quick stopping of the equipment in emergency situations
Alarm Information Area
Hierarchically displays various alarm and reminder information, including warning level and information level
Each alarm contains a title, detailed description, and occurrence time
Supports viewing complete alarm records for easy fault tracing and analysis
Real-time Data Indicators Area
Centralizes the display of key operating parameters: exhaust pressure, exhaust temperature, motor current, and energy consumption
Each indicator includes the current value and the current trend indication for today
Uses a light background card design to highlight data readability
Run Trend Chart Area
Multi-parameter trend curves: Show the 24-hour change trends of pressure, temperature, and energy consumption simultaneously
Multi-axis design: Uses independent axes for different parameter numerical ranges
Time range switching: Supports viewing data trends for today, this week, and this month
System Information Area
Equipment Information: Includes model, serial number, installation date, and maintenance record
System Status: Displays system parameters such as software version, communication status, IP address, etc.
Maintenance Reminder: Clearly indicates the estimated time for the next maintenance.
