The core features and applications of the electromagnetic valve of the Atlas Copco oil-separation type air compressor are as follows: Main Function:
Oil-gas separator control: Some solenoid valves are used to control the pressure balance or discharge of the oil-gas separator, ensuring that the separator can effectively separate oil from compressed air and guarantee that the exhaust quality meets standards.
Return oil pipeline control: In the return oil process after oil-gas separation, the solenoid valve can be combined with one-way valves and other components to control the return oil flow and timing, avoiding excessive consumption of lubricating oil or poor return oil resulting in insufficient compressed air volume.
System pressure regulation: Linked with pressure sensors, by controlling the opening and closing of specific air paths, it assists in regulating the working pressure of the oil-gas separation system, maintaining system stability.
Adaptation to environmental characteristics:
Due to direct contact with oily compressed air or lubricating oil, the valve body material mostly selects oil-resistant and corrosion-resistant brass or stainless steel, and the sealing components use oil-resistant rubber (such as nitrile rubber), which can long-term withstand the erosion of the oil-gas environment.
Working pressure is usually matched with the rated exhaust pressure of the compressor (such as 8-16Bar is common), and the voltage specification varies according to the electrical design of the model, including AC24V, AC110V, AC220V, etc. It must strictly correspond to the equipment parameters.
