1092110800 Atlas Copco

The core function of the transmission shaft sealing kit for 1092110800 Atlas Copco screw air compressors

The main role of the transmission shaft sealing kit is to prevent the lubricating oil inside the compressor from leaking out along the transmission shaft, and to prevent external air, dust, moisture, and other impurities from entering the compressor through the gap between the shaft and the body, thereby ensuring the sealing performance of the lubrication system and the cleanliness of the compressed air, and avoiding oil loss, environmental pollution, or internal component contamination and wear caused by leakage.

Typical components

The kit usually contains various sealing elements, and may include:

Frame oil seal ;O-rings, sealing gaskets, etc. as auxiliary sealing components;

May include dust shields;Some kits may come with installation-required positioning rings or guide sleeves and other small components.

Material and design features The sealing elements mostly use elastic materials that are resistant to oil, high temperature, and wear, to adapt to the oil environment and working temperature inside the compressor;

The frame oil seal usually adopts a structure combining metal frame and rubber to ensure the rigidity and fit of the sealing component, ensuring a good sealing effect even when the shaft rotates;

The size accuracy is strictly matched to the mating tolerance of the transmission shaft and the body, ensuring a close fit after installation without excessive friction that leads to premature wear.

Original equipment advantages

Precise fit: As an original factory part, the kit's size, material, and specific to the transmission shaft system of the screw compressor are completely matched, avoiding sealing failure or shaft system wear caused by non-original part size deviations;

Durability guarantee: The materials and processes comply with 1092110800 Atlas Copco's strict standards, with better anti-aging and anti-wear performance, extending the replacement cycle;

System compatibility: Compatible with the lubricating oil type, working pressure, etc. of the compressor, avoiding sealing component swelling or hardening due to incompatible materials with the oil.
