Atlas Copco 2906035200,The intake valve is the "breathing hole" of the air compressor, responsible for controlling the amount of fresh air intake to ensure the normal operation of the compressor and the output of compressed gas meeting the requirements. The intake valve is controlled on and off by the solenoid valve to achieve automatic loading and unloading of the compressor 5. When the pressure does not reach the set value, the intake valve is fully opened for loading; when the pressure is too high, it automatically unloads to protect the equipment and reduce energy consumption. The intake valve regulates the intake volume to control the output pressure and flow of the compressor, meeting the needs of different working conditions. The intake valve is equipped with a check valve to prevent reverse flow of compressed air and avoid damage to the exhaust system. The bypass valve of the intake valve is open during no-load or shutdown to prevent the formation of a vacuum in the separation oil tank and ensure the normal atomization and circulation of lubricating oil.

Usage and Maintenance Notes Strictly match the model Different series of air compressors (such as GA, GHS, ZR, etc.) require the use of corresponding model-specific oils. Mixing or using the wrong type may cause equipment damage and affect warranty. Regular replacement and inspection Replace according to the specified cycle in the equipment manual (synthetic oil usually has a longer cycle than mineral oil), and replace oil filters, air filters, etc. at the same time. Regularly test the oil quality (such as viscosity, moisture content, impurity content) to avoid failures caused by deteriorated oil. Storage and refilling The oil needs to be stored in a sealed manner in a cool and dry place to avoid contamination; when refilling, ensure that the tools are clean to prevent impurities from entering the oil circuit system.

Maintenance and Replacement Suggestions for Air Filters of Atlas Copco Screw Air Compressors Replacement Cycle: Generally, it is recommended to replace the air filter according to the specified cycle in the equipment maintenance manual (such as after 2000-4000 hours of operation, which may vary depending on the model and usage environment). If the dust concentration in the usage environment is high (such as in mines or cement plants), the replacement cycle should be shortened. Inspection Method: Regularly (e.g., weekly) check the cleanliness of the air filter. You can determine if it is clogged by using a pressure differential indicator (available on some models) — when the indicator value exceeds the set threshold, it is necessary to replace it promptly. Replacement Precautions: During replacement, ensure proper installation and good sealing; avoid allowing impurities to fall into the intake pipe during disassembly and assembly. After replacement, check for any leakage.

2906065600 Maintenance and Replacement Instructions for the Transmission Shaft Seal Kit of Atlas Copco Screw-Type Air Compressor If oil stains are found near the transmission shaft or there is oil leakage, or if the consumption of compressor lubricating oil increases abnormally, this may be due to the aging or damage of the seal kit. Therefore, it is necessary to check and replace it in time. When replacing, it is recommended to use the original seal kit and follow the equipment manual for operation to ensure that the installation direction of the sealing piece is correct and it is tightly attached. If necessary, special tools can be used for installation to avoid deformation or damage to the sealing piece.

I.Main Components Included in the Set。 Air filter Filters out dust and impurities in the air to prevent them from entering the compressor. It is recommended to replace every 4000 hours to avoid blockage that leads to a decrease in air volume and increased energy consumption. Oil filter Filters impurities in the lubricating oil to protect key components such as bearings and gears. Blockage will cause an increase in oil pressure, triggering a protective shutdown. Oil-gas separator Separates the lubricating oil from the compressed air to ensure that the exhaust contains an acceptable amount of oil (typically ≤ 3ppm). Failure will result in increased fuel consumption, oil in the exhaust, and contamination of the after-treatment equipment. Lubricating oil Synthetic lubricants (such as the SynthOil series from Atlas Copco) provide lubrication, cooling and sealing functions. They need to be replaced every 4,000 hours. Old lubricants will reduce cooling efficiency and increase the risk of carbon deposits. Sealing kit Includes O-rings, gaskets, etc., to prevent leakage of lubricating oil and compressed air. Old sealing parts may cause a decrease in pressure or oil leakage. Other accessories Some packages may include belts (belt drive type), sensors, hoses, etc. II. Advantages of the Maintenance Package One-stop purchase: A single package covers all the replacement needs of key components, avoiding the omission of accessories. Original factory matching: Atlas Copco original accessories ensure perfect compatibility with the equipment, extending the service life. Cost-effectiveness: The package price is usually more favorable than purchasing accessories separately. Professional guidance: A detailed maintenance manual is included, guiding users on how to replace the accessories correctly.

Atlas Copco 0634100085，The coupling transmits the motor torque stably to the compressor rotor, ensuring the normal operation of the air compressor. This is its most fundamental function, applicable to high-power and high-speed scenarios. Overload protection: In case of abnormality in the motor or rotor, the coupling can quickly disconnect the connection to prevent equipment damage. Buffering and shock absorption: Absorbing vibrations and shocks caused by startup, shutdown or load changes, reducing equipment wear. Offset compensation It can compensate for axial, radial and angular offsets caused by manufacturing and installation errors, thermal expansion or deformation, ensuring the alignment accuracy of the shaft. Adaptability to complex working conditions High load/High speed: Suitable for high-torque and high-speed environments, ensuring the stability of the transmission system. Safe and reliable: Some couplings are designed with safety devices, automatically disconnecting the connection when the load exceeds the limit.
