Products

Atlas Copco 2906908000,The Atlas Copco Air Compressor Blade Inspection Kit is a professional toolset specifically designed for the inspection and maintenance of air compressor blades. It offers preventive inspections that provide comprehensive lifecycle detection services, including verification of raw material composition, measurement of dimensional accuracy, and scanning of surface defects, among other integrated solutions. Through regular inspections, potential problems with the blades can be identified in a timely manner, preventing sudden failures that cause equipment downtime. The kit also analyzes and diagnoses blade surface defects, such as cracks, damages, erosion or wear marks, assesses the aerodynamic performance and fatigue strength of the blades, predicts deformation risks and service life. Performance evaluation and optimization analyze the residual stress of the blades and make predictions.

Atlas Copco 1901064370，The Atlas Copco intake valve controls the intake volume by adjusting the opening degree of the intake port according to the pressure changes in the storage tank, achieving loading and unloading control, and protecting the function to prevent a large amount of gas from entering the compressor head when it starts, reducing the starting current of the motor, and operating in a regular pattern of being loaded when powered and unloaded when power is lost. It has a capacity adjustment control function. Minimum pressure valve pressure establishment: When the equipment starts, it quickly establishes the circulating pressure required for lubrication, and the buffer protection control through the gas flow rate of the oil-gas separation filter to prevent high-speed gas flow from damaging the separation effect. Check valve function: Prevents the gas in the storage tank from flowing back to the oil-gas tank. Safety valve overpressure protection: Automatically opens when the system pressure exceeds the specified value, discharging the gas into the atmosphere. Safety device: Prevents pressure equipment and containers from bursting due to excessive pressure, and automatically controls: Automatically closes when the pressure drops to the specified value, ensuring the safe operation of the equipment. Temperature control valve temperature regulation: Controls the proportion of lubricating oil entering the oil cooler according to the principle of thermal expansion and contraction. Temperature protection ensures that the rotor temperature is within the set range, preventing excessive or insufficient temperature. When the refrigeration machine starts, it forces the lubricating oil to enter the compressor head directly without passing through the cooler, achieving rapid heating. Electromagnetic valve control system has two types of medium regulation for loading and venting: used to adjust the bias, flow rate, speed, on-off parameters and precisely control the connection and disconnection of the oil-gas tank to the intake valve through the cylinder pipeline under PLC instructions.

Atlas Copco 2906037800，The intermediate cooler of the air compressor is an important component of the compressor unit, primarily responsible for three core functions: heat exchange, temperature control, and system protection. The cooling and heat dissipation process reduces the temperature of the high-temperature compressed air discharged by the primary compressor from 186°C to around 54°C, providing suitable temperature conditions for the secondary compression stage. It also cools the liquid temperature before it enters the main expansion mechanism, reducing throttling losses. It enhances the compression efficiency. It enables isothermal compression, optimizes compression efficiency, ensures the outlet pressure and temperature indicators, reduces heat loss, and improves the overall operational efficiency of the unit. System protection prevents the exhaust temperature from exceeding the allowable value due to excessively high suction temperature at the high-pressure stage, providing an oil separation function to separate the oil and moisture in the compressed air.

Atlas Copco 1608047300,The minimum pressure valve of the air compressor, also known as the pressure maintenance valve, is a crucial control component in the air compressor system. It is used to establish the system pressure. When the air compressor starts, the minimum pressure valve closes, helping to quickly establish an initial pressure of 0.4-0.5 MPa, ensuring the circulation pressure required for the lubricating oil, and preventing equipment from wearing out due to poor lubrication. It protects the oil-gas separation system when the pressure exceeds 0.45 MPa. The valve opens, reducing the air flow rate passing through the oil-gas separator, ensuring the oil-gas separation effect and protecting the oil-gas separation filter from damage due to excessive pressure difference. It has a one-way valve function to prevent the compressed air in the storage tank from flowing back to the air compressor when it stops. It prevents pressure leakage in the no-load state and ensures the lubricating oil circulation. The buffering protection function buffers the impact of large pressure differences on the separator core at the moment of machine loading, controls the gas flow rate passing through the oil-gas separation filter, and prevents high-speed airflow from damaging the oil-gas separation effect.

Atlas Copco 2906082800,The air compressor maintenance kit is an essential component for ensuring the safe operation of the air compressor system. It is mainly used for preventive maintenance and upkeep, ensuring the long-term stable operation of the equipment. The core protection function is to monitor the temperature of the storage tank, cooling water outlet temperature, and other parts through over-temperature protection. When the temperature reaches ≥ 120℃, it triggers an audible and visual alarm and automatically shuts down the machine. Overpressure protection: It detects the pressure of the storage tank in real time. When the pressure exceeds the limit, it automatically shuts down to protect the equipment safety. Oil shortage protection: It monitors the pressure of the lubrication system. When the oil pressure is abnormal, it forcibly shuts down to prevent mechanical dry friction damage. Water shortage protection: Specifically for water-cooled air compressors, it triggers a shutdown when the cooling water flow is abnormal. The filtration system functions as follows: The air filter: Filters impurities in the air entering the air compressor, such as dust, particles, and oil stains, to ensure the quality of the compressed air. The oil separator: Separates the lubricating oil from the compressed air to ensure the recycling of the lubricating oil and reduce the oil content in the compressed air. The oil filter: Filters the impurity particles in the lubricating oil to maintain the cleanliness of the lubricating oil.

Atlas Copco 2906000600,Reducing gas temperature in multi-stage compression process, after the gas passes through the previous stage of compression, its temperature will rise sharply. The intercooler is located between the compression stages and can cool the high-temperature gas, providing lower-temperature and denser gas for the next stage of compression. Enhancing system efficiency The cooling process makes the compression process closer to isothermal compression, thereby reducing power consumption and improving the operational efficiency and economy of the entire compressor system. Separating condensate When the gas temperature drops, the water vapor and oil-gas mixture contained therein will condense. Some lubricating oil and water will condense into droplets, which can then be separated out, making the output compressed air cleaner. By effectively controlling the gas temperature, risks such as lubricant failure, equipment component damage, and even explosion caused by excessively high temperatures can be prevented. At the same time, the pollution risks to downstream equipment and pipelines can also be reduced.
