1626088200 If the oil filter of Atlas Copco gets clogged or its filtering efficiency declines, it will lead to an increase in the resistance of oil flow, insufficient oil supply, and at the same time, the entry of impurities into key components will aggravate wear, increase the risk of faults, and even potentially cause serious problems such as the engine getting stuck.

For the Atlas Copco 1625599900 820 model hose, when installing it, make sure that the joints at both ends of the hose are securely connected to prevent leakage. During daily use, regularly check if the hose has any signs of aging, cracking, damage, bulging, etc. If any problems are found, replace it immediately to prevent system failures or safety hazards caused by the failure of the hose.

1622908920 The internal structure of the Atlas Copco check valve is equipped with a valve core, which only allows the lubricating oil to flow in the preset direction. When the oil flow direction is reversed, the valve core will automatically close the channel to prevent backflow. When the compressor stops, the oil pressure in the system drops sharply. Without the 1622908920 Atlas Copco check valve, the lubricating oil may flow in the opposite direction due to gravity or residual system pressure, causing the internal components of the main unit and bearing parts to experience dry friction when the compressor starts up again, thereby accelerating wear.

When the compressor starts, the lubricating oil temperature is relatively low. The 1622706404 Atlas Copco temperature stabilizing valve will close the oil passage leading to the cooler, allowing the lubricating oil to directly enter the compressor for lubrication and cooling, thereby accelerating the increase in oil temperature. When the oil temperature reaches around 60 degrees Celsius, the 1622706404 Atlas Copco temperature stabilizing valve will gradually open the passage leading to the cooler, allowing some or all of the lubricating oil to flow through the cooler for cooling, thus maintaining the oil temperature within the ideal working range of around 60 degrees Celsius.

1621875099 Atlas Copco filter material: Usually, it uses ultra-fine glass fiber composite filter material from the US HV Company or pure wood pulp filter paper from the Korean Ahlstrom Company. These filter materials have excellent filtering performance and can effectively retain impurity particles of 10-15 microns. 1621875099 The filtration accuracy of Atlas Copco is generally 10-15 micrometers, with a filtration efficiency of approximately 99%. The working temperature range is usually between -10℃ and 100℃, and the working pressure can reach 1.6 MPa.

1617965500 Atlas Copco Installation Location: The filter element can be installed at any position in the compressed air system. It can be standardly equipped on the after-cooler and is highly flexible to use. It can effectively protect the compressed air system as well as components such as dryers and filters.
